Kanak Fittings stands out as a top-notch manufacturer and supplier of high-quality pipe fittings in Dubai, UAE. They specialize in producing premium 5° Long Radius Elbows and 45° Short Radius Elbows. With a strong focus on excellence and innovation, Kanak Fittings ensures that their products meet international standards for durability and performance. They cater to various industries, including oil and gas, petrochemicals, construction, and power generation. Renowned for their precision and reliability, Kanak Fittings provides customized solutions to address diverse customer needs, guaranteeing efficient and long-lasting performance in piping systems.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 45° Long Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 45° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 45° Long Radius Elbow
When it comes to the composition and mechanical properties of 5° Long Radius and 45° Short Radius Elbows, these fittings are crafted from materials like stainless steel, carbon steel, and high-strength alloys to ensure they are durable and resistant to corrosion. Their composition features elements such as chromium, nickel, and molybdenum, which contribute to their excellent thermal stability and mechanical strength. These elbows boast high tensile and yield strength, making them perfect for high-pressure and high-temperature applications. Manufactured in accordance with ASTM, ANSI, and API standards, they offer precision engineering that ensures structural integrity, wear resistance, and compatibility with a wide array of piping systems.
Stainless Steel 45° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 45° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 45° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6
Kanak Fittings is a leading supplier of 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow in Dubai, UAE. We offer an extensive range of 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow from Kanak Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
45° Long Radius and 45° Short Radius Elbows offer distinct advantages depending on application needs. The Long Radius Elbow provides a gradual, smooth bend, ensuring minimal pressure loss and efficient flow, making it ideal for high-velocity systems. It is commonly used in larger piping setups. The Short Radius Elbow, on the other hand, is perfect for compact installations with limited space, offering quick directional changes. Both types are highly durable, corrosion-resistant, and made from strong materials like stainless steel, ensuring long-lasting performance in industries such as oil and gas, HVAC, and chemical processing.
Yes, custom sizes for 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.
| NPS | O.D. D | 90 degrees Long Radius Center-to-End A | 45 degrees Long Radius Center-to-End B | 90 degrees 3D Center-to-End A | 45 degrees 3D Center-to-End B |
| 1/2 | 21.3 | 38 | 16 | – | – |
| 3/4 | 26.7 | 38 | 19 | 57 | 24 |
| 1 | 33.4 | 38 | 22 | 76 | 31 |
| 1 ¼ | 42.2 | 48 | 25 | 95 | 39 |
| 1 ½ | 48.3 | 57 | 29 | 114 | 47 |
| 2 | 60.3 | 76 | 35 | 152 | 63 |
| 2 ½ | 73 | 95 | 44 | 190 | 79 |
| 3 | 88.9 | 114 | 51 | 229 | 95 |
| 3 ½ | 101.6 | 133 | 57 | 267 | 111 |
| 4 | 114.3 | 152 | 64 | 305 | 127 |
| 5 | 141.3 | 190 | 79 | 381 | 157 |
| 6 | 168.3 | 229 | 95 | 457 | 189 |
| 8 | 219.1 | 305 | 127 | 610 | 252 |
| 10 | 273 | 381 | 159 | 762 | 316 |
| 12 | 323.8 | 457 | 190 | 914 | 378 |
| 14 | 355.6 | 533 | 222 | 1067 | 441 |
| 16 | 406.4 | 610 | 254 | 1219 | 505 |
| 18 | 457 | 686 | 286 | 1372 | 568 |
| 20 | 508 | 762 | 318 | 1524 | 632 |
| 22 | 559 | 838 | 343 | 1676 | 694 |
| 24 | 610 | 914 | 381 | 1829 | 757 |
| 26 | 660 | 991 | 406 | 1981 | 821 |
| 28 | 711 | 1067 | 438 | 2134 | 883 |
| 30 | 762 | 1143 | 470 | 2286 | 964 |
| 32 | 813 | 1219 | 502 | 2438 | 1010 |
| 34 | 864 | 1295 | 533 | 2591 | 1073 |
| 36 | 914 | 1372 | 565 | 2743 | 1135 |
| 38 | 965 | 1448 | 600 | 2896 | 1200 |
| 40 | 1016 | 1524 | 632 | 3048 | 1264 |
| 42 | 1067 | 1600 | 660 | 3200 | 1326 |
| 44 | 1118 | 1676 | 695 | 3353 | 1389 |
| 46 | 1168 | 1753 | 727 | 3505 | 1453 |
| 48 | 1219 | 1829 | 759 | 3658 | 1516 |
As for their uses and applications, 5° Long Radius Elbows are ideal for facilitating smooth directional changes in pipelines, helping to minimize turbulence and pressure loss. This makes them perfect for gradual flow transitions in the oil, gas, and chemical industries. On the other hand, 45° Short Radius Elbows are designed for tighter spaces that require sharp directional changes, often found in HVAC systems, water distribution, and process industries. Their sturdy construction and corrosion resistance make them well-suited for transporting abrasive and high-temperature fluids. These elbows play a crucial role in ensuring efficient flow management and reducing operational wear, providing versatile solutions across both industrial and commercial settings.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
