Kanak Fittings stands out as a leading manufacturer and supplier of Monel K500 Forged Fittings, proudly based in Dubai, UAE. They specialize in creating high-strength, corrosion-resistant piping components that cater to vital industries like marine, oil and gas, chemical processing, and aerospace. Monel K500 forged fittings are celebrated for their remarkable mechanical strength and outstanding resistance to both seawater and acidic environments. By blending advanced forging techniques with rigorous quality assurance, Kanak Fittings ensures that their products meet international standards. With a strong focus on durability, precision, and customer satisfaction, they have earned a reputation as a reliable supplier in both the UAE and global markets.
Specifications ASTM B366 / ASME SB366
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79
Size Seamless 1/2″ – 10″ , Welded 1/2″ – 48″
Type (Seamless & 100% X-Ray Welded, Fabricated)
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Grade Monel K500 Pipe Fittings UNS (N05500), DIN (2.4375)
Monel K500 Forged Fittings are primarily made up of nickel (about 63%) and copper (28-34%), along with trace amounts of iron, manganese, aluminum, and titanium. This distinctive blend boosts the alloy’s strength and hardness through a process called precipitation hardening, all while preserving excellent corrosion resistance. On the mechanical side, Monel K500 boasts a tensile strength ranging from approximately 830 to 1030 MPa and a yield strength between 380 and 690 MPa, along with good ductility and toughness. The alloy maintains its impressive properties across a wide range of temperatures and harsh environments, making it perfect for demanding applications.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 115000 , MPa – 790 | Psi – 160000 , MPa – 1100 | 20 % |
Kanak Fittings is a leading supplier of Monel K500 Buttweld Fittings in Dubai, UAE. We offer an extensive range of Monel K500 Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WNR. |
| Monel K500 | N05500 | 2.4375 |
Choose Monel K500 Buttweld Fittings from Kanak Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Monel K500 Buttweld Fittings offer superior strength, corrosion resistance, and durability, making them ideal for harsh environments. The addition of titanium and aluminum enhances their mechanical properties, offering increased hardness and resistance to wear. These fittings are highly resistant to corrosion in seawater, acidic, and alkaline conditions, ensuring long-term reliability in industries such as marine, chemical processing, and oil & gas. Monel K500 also maintains its strength at elevated temperatures and resists stress corrosion cracking, making it suitable for high-pressure, high-temperature applications. Their excellent weldability further enhances their versatility.
Yes, custom sizes for Monel K500 Buttweld Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae
Monel K500 Forged Fittings find their place in settings where high strength and corrosion resistance are crucial. In the marine sector, they are commonly used in seawater systems, valves, and pump components due to their ability to resist biofouling and corrosion. The oil and gas industry relies on them for offshore platforms and pipelines that face sour gas and acidic conditions. Chemical processing facilities utilize Monel K500 fittings for managing aggressive chemicals and high-pressure fluids. In aerospace, the alloy’s strength-to-weight ratio and durability make these fittings ideal for critical high-performance systems.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
