Hastelloy C22 Pipe Fittings Manufacturer and Supplier in Dubai, UAE

Kanak Fittings stands out as a leading manufacturer and supplier of Hastelloy C22 Pipe Fittings in Dubai, UAE. Known for their precision-engineered, high-performance solutions, they cater to various industries, including chemical processing, oil and gas, and marine engineering. With a strong commitment to quality, innovation, and customer satisfaction, Kanak Fittings guarantees that all their products meet rigorous international standards. Their state-of-the-art manufacturing facilities and expertise in Hastelloy C22 allow them to deliver fittings that are not only highly durable and corrosion-resistant but also suitable for a wide array of demanding applications.

Hastelloy C22 Stub End In UAE, Hastelloy C22 Buttweld Elbow Sharjah, ASTM B366 Hastelloy Alloy C22 Pipe Fittings Dubai, Hastelloy C22 Reducing Tee Abu Dhabi, Hastelloy® C22 Pipe Fittings in Jebel Ali, ASME SB366 Hastelloy® Alloy C22 Pipe Cap Al Ain, Hastelloy C22 Buttweld Fittings Ajman.

Hastelloy C22 Pipe Fittings Specification

Specification : ASTM B366 / ASME SB366

Dimension Standard : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

ASME B16.9 : standard for – Factory-Made Wrought Buttwelding Fittings

ASME B16.25 : Buttwelding Ends

ASME B16.28 : standard for – Butt-Welded Short Radius Elbows & Returns Bends

MSS SP-43 : Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Size Range : ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)

Seamless Butt Weld Fitting Size : 1/2″ – 10″

Welded Butt Weld Fittings Size : 1/2″ – 48″

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Type : Seamless / Welded / Fabricated

Hastelloy C22 Pipe Fittings are crafted from a nickel-chromium-molybdenum alloy, enhanced with iron and tungsten, which provides outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking. They boast high tensile strength and excellent thermal stability, ensuring reliable performance even in extreme conditions. The unique blend of elements in this alloy offers superior resistance to both oxidizing and reducing environments. These fittings comply with ASTM B366 standards and are designed to maintain their structural integrity and durability, even in harsh chemical settings, making them a top choice for critical industrial applications.

Hastelloy C22 Pipe Fittings Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
Alloy C22	0.010 max	0.50 max	0.08 max	0.02 max	2.50 max	50.015 min*	20.00 – 22.50	2.00 – 6.00	12.50 – 14.50	0.02 max

Hastelloy C22 Pipe Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %

Equivalent Grades for Hastelloy C22 Pipe Fittings

STANDARD	UNS	WERKSTOFF NR.	JIS	EN
Hastelloy C22	N06022	2.4602	NW 6022	NiCr21Mo14W

Hastelloy C22 45 deg. Elbow In UAE, Hastelloy C22 Reducer Sharjah, Hastelloy C22 90 deg Elbow Dubai, ANSI B16.9 Hastelloy C22 Buttweld Pipe Fittings Suppliers in Abu Dhabi, Hastelloy C22 Pipe Bend in Jebel Ali, Hastelloy® C22 Pipe Fittings Price List in Al Ain, Hastelloy C22 Pipe Elbow Suppliers Ajman, Hastelloy C22 Seamless Pipe Fittings UAE.

Largest Hastelloy C22 Pipe Fittings Supplier in Dubai, UAE

Kanak Fittings is a leading supplier of Hastelloy C22 Pipe Fittings in Dubai, UAE. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Hastelloy C22 Pipe Fittings Dimensions

Nominal Pipe Size	All Fittings	All Fittings	All Fittings	Elbows/ Tees	180° Return Bends	180° Return Bends	180 Deg Return Bends	Reducers	Caps
NPS	O.D. at Bevel (1), (2)	I.D. at End (1), (3), (4)	Wall Thickness (3)	Centre-to-End Dimension A,B,C,M	Centre-to-Centre O	Back-to-Face K	Alignment of Ends U	Overall Length H	Overall Length E
½ to 2½	0.06 -0.03	0.03	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
3 to 3 ½	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
4	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
5 to 8	0.09 -0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.25
10 to 18	0.16 -0.12	0.12	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
20 to 24	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
26 to 30	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.12	…	…	…	0.19	0.38
32 to 48	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.19	…	…	…	0.19	0.38

Why Choose Hastelloy C22 Pipe Fittings from Kanak Fittings?

Hastelloy C22 Pipe Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Hastelloy C22 Buttweld Cross Manufacturers UAE, Hastelloy C22 Welded Pipe Fittings Exporter in Sharjah, Hastelloy C22 Elbow Dubai, ASTM B366 Hastelloy C22 Tee Abu Dhabi, ASME SB366 Hastelloy C22 Unequal Tee Jebel Ali, Hastelloy® C22 Straight Tees Al Ain, ASME / ANSI B16.9 Hastelloy C22 Short Stub End Ajman.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Hastelloy C22 pipe fittings offer exceptional resistance to corrosion, particularly in oxidizing and reducing environments, making them ideal for chemical processing. They withstand high temperatures and aggressive chemicals, including chlorides, acids, and oxidizing agents, enhancing durability in extreme conditions. Their superior weldability and machinability ensure ease of fabrication. With excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, they maintain structural integrity in demanding applications. These fittings are versatile, suitable for pharmaceutical, marine, and power industries, ensuring long-term reliability, reduced maintenance, and cost-efficiency in critical environments.

Types of Hastelloy C22 Pipe Fittings

Are Custom Sizes Available for Hastelloy C22 Pipe Fittings?

Yes, custom sizes for Hastelloy C22 Pipe Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.

Hastelloy C22 45 deg. Elbow In UAE, Hastelloy C22 Reducer Sharjah, Hastelloy C22 90 deg Elbow Dubai, ANSI B16.9 Hastelloy C22 Buttweld Pipe Fittings Suppliers in Abu Dhabi, Hastelloy C22 Pipe Bend in Jebel Ali, Hastelloy® C22 Pipe Fittings Price List in Al Ain, Hastelloy C22 Pipe Elbow Suppliers Ajman, Hastelloy C22 Seamless Pipe Fittings UAE.

Application Industry of Hastelloy C22 Pipe Fittings

Hastelloy C22 Pipe Fittings are perfect for applications that demand exceptional resistance to corrosion and chemical reactions. They are widely utilized in sectors such as chemical processing, pharmaceuticals, pollution control, and marine engineering, effortlessly handling aggressive substances like hydrochloric acid and sulfuric acid. These fittings are crucial in high-pressure and high-temperature scenarios, including heat exchangers, reactors, and pipelines. Their remarkable durability and corrosion resistance make them ideal for systems that transport corrosive fluids and gases, ensuring reliability and long-lasting performance in essential industrial processes.
