Vishal Flanges, based in Delhi, India, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Copper Nickel threaded flanges. These flanges are celebrated for their outstanding resistance to corrosion and impressive strength, making them perfect for tough marine and industrial environments. With a commitment to quality and precision, Vishal Flanges guarantees that each product adheres to international standards. Our Copper Nickel threaded flanges are not only dependable and durable but also versatile, making them a go-to choice for clients worldwide across various industrial sectors.
| Specification : | ASTM A182 F11 Forged Fittings |
|---|---|
| Thread Connections | ASME B16.11 (Socket Welding and Threaded) Fittings, MSS-SP-83 (Class Unions) Fittings, ASME B16.3 (Malleable Iron Fittings) Fittings, ASME B16.4 ( Gray Iron Fittings) Fittings, ASME B16.39 (Malleable Iron Unions) Fittings, ASME B16.34 (Valves — Flanged) Fittings, ASME B16.39 (Malleable Iron Pipe Unions, 150#, 250#, Or 300#) Fittings. |
| Standards | ASME B16.11 (American Standard), Bs3799, MSS SP 79, JIS B2302, MSS-SP-97 (Threadolet), MSS-SP-83 (Union), ASME B36.19 (Nipple) |
| Types Of Thread | NPT Fittings, BSPP Fittings, BSPT Fittings, PF Fittings, PT Fittings, MPT Fittings |
| Applications | Oil and Gas Chemical Power station Water Pipeline Noncritical Applications Fire Protection |
| Advantages Of | Simple Usage Easy installation Economic as cheaper |
| Size | Threaded Fittings = ½” – 4” |
| Pressure Rating | Threaded Fittings = Class 2000, Class 3000, Class 6000 |
| Type Of Pipe systems | 45 Deg Elbow, Equal tee, Full Coupling, Reducing Tee, 90 Deg Elbow, Half Coupling, Street Elbow, Bull Plug, Boss, Union (Male/Female), Lateral Outlet, 45 Lateral Tee, Equal Cross, Pipe Cap, Branch Outlets, Swage Nipple. |
Copper Nickel threaded flanges are primarily made up of copper (60%-70%) and nickel (30%-40%), with trace amounts of iron and manganese to enhance strength and corrosion resistance. This special blend provides remarkable protection against seawater corrosion, biofouling, and stress cracking. These flanges showcase moderate tensile strength, high ductility, and excellent thermal stability, ensuring they perform reliably under high-pressure and high-temperature conditions. Their mechanical properties make them perfect for long-term use in challenging environments.
| Gr | C | Mn | Si | S | P | Cr | Mo |
| ASTM A182 F11 Forged Fittings | 0.05 – 0.15 | 0.3 – 0.6 | 0.5 – 1 | 0.03 | 0.03 | 1 – 1.5 | 0.044 – 0.65 |
| Gr | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| ASTM A182 F11 Forged Fittings | 205 | 415 | 20 |
Kanak Fittings is a leading supplier of Alloy Steel F11 Forged Fittings in Dubai, UAE. We offer an extensive range of Alloy Steel F11 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Alloy Steel F11 Forged Fittings from Kanak Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Alloy Steel F11 Forged Fittings are primarily composed of carbon, manganese, phosphorus, sulfur, and silicon, with chromium (2.25-3%) and molybdenum (0.9-1.1%) as key alloying elements. Chromium enhances oxidation and corrosion resistance, while molybdenum improves strength and heat resistance. The mechanical properties include a tensile strength of approximately 585 MPa, yield strength of 415 MPa, and an elongation of around 20%. These fittings also exhibit good impact toughness, making them ideal for high-pressure, high-temperature applications. Alloy Steel F11 Forged Fittings offer long-lasting performance in demanding industrial environments.
Yes, custom sizes for Alloy Steel F11 Forged Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.
| STANDARD | UNS | WERKSTOFF NR. | Trade Name |
| ASTM A182 F11 Forged Fittings | K11597 | 1.7338 | 1-1/4Cr-1/2Mo |
| DN | NPS | Center to End NPT Elbow, NPT Tee, NPT Cross A | Center to End 45 Deg Elbow C | O.D. of Band H | Min. Wall Thick. G | Length of Thread. Minimum (1) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | B | L2 | ||
| 6 | 1/8 | 21 | 21 | 25 | 17 | 17 | 19 | 22 | 22 | 25 | 3.18 | 3.18 | 6.35 | 6.4 | 6.7 |
| 8 | 1/4 | 21 | 25 | 28 | 17 | 19 | 22 | 22 | 25 | 33 | 3.18 | 3.30 | 6.60 | 8.1 | 10.2 |
| 10 | 3/8 | 25 | 28 | 33 | 19 | 22 | 25 | 25 | 33 | 38 | 3.18 | 3.51 | 6.98 | 9.1 | 10.4 |
| 15 | 1/2 | 28 | 33 | 38 | 22 | 25 | 28 | 33 | 38 | 46 | 3.18 | 4.09 | 8.15 | 10.9 | 13.6 |
| 20 | 3/4 | 33 | 38 | 44 | 25 | 28 | 33 | 38 | 46 | 56 | 3.18 | 4.32 | 8.53 | 12.7 | 13.9 |
| 25 | 1 | 38 | 44 | 51 | 28 | 33 | 35 | 46 | 56 | 62 | 3.68 | 4.98 | 9.93 | 14.7 | 17.3 |
| 32 | 1-1/4 | 44 | 51 | 60 | 33 | 35 | 43 | 56 | 62 | 75 | 3.89 | 5.28 | 10.59 | 17.0 | 18.0 |
| 40 | 1-1/2 | 51 | 60 | 64 | 35 | 43 | 44 | 62 | 75 | 84 | 4.01 | 5.56 | 11.07 | 17.8 | 18.4 |
| 50 | 2 | 60 | 64 | 83 | 43 | 44 | 52 | 75 | 86 | 102 | 4.27 | 7.14 | 12.09 | 19.0 | 19.2 |
| 65 | 2-1/2 | 76 | 83 | 95 | 52 | 52 | 64 | 92 | 102 | 121 | 5.61 | 7.65 | 15.29 | 23.6 | 28.9 |
| 85 | 3 | 86 | 95 | 106 | 64 | 64 | 79 | 109 | 121 | 146 | 5.99 | 8.84 | 16.64 | 25.9 | 30.5 |
| 100 | 4 | 106 | 114 | 114 | 79 | 79 | 79 | 146 | 152 | 152 | 6.55 | 11.18 | 18.67 | 27.7 | 33.0 |
| Normal Pipe Size | A | B | QTY | Weight In KG |
|---|---|---|---|---|
| ¼ | 0.81 | 0.88 | 160 | 0.20 |
| ⁄ | 0.97 | 1.00 | 130 | 0.26 |
| ½ | 1.12 | 1.31 | 100 | 0.57 |
| ¾ | 1.31 | 1.5 | 75 | 0.71 |
| 1 | 1.5 | 1.81 | 40 | 1.08 |
| 1 ¼ | 1.75 | 2.19 | 25 | 1.68 |
| 1 ½ | 2.00 | 2.44 | 18 | 2.38 |
| 2 | 2.38 | 2.97 | 10 | 3.55 |
| 2 ½ | 3.00 | 3.62 | 4 | 6.22 |
| 3 | 3.38 | 4.31 | 2 | 10.36 |
| 4 | 4.19 | 5.75 | 1 | 23.91 |
Vishal Flanges’ Copper Nickel threaded flanges find extensive applications in industries like marine, shipbuilding, offshore oil and gas, and desalination plants. Their exceptional resistance to seawater corrosion makes them ideal for piping systems, heat exchangers, and condenser systems. Additionally, these flanges are utilized in chemical processing, power generation, and HVAC systems. Built for durability and flexibility, Copper Nickel threaded flanges provide secure and leak-proof connections in critical applications, ensuring long-lasting reliability even in harsh operating conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
