Kanak Fittings has established itself as a reliable name in the manufacturing and supply of Duplex Steel UNS S32205 Forged Fittings in Dubai, UAE. Known for their precision and durability, these fittings are crafted to meet the rigorous demands of industries like oil and gas, petrochemicals, and water treatment. With a strong focus on quality, the company follows global standards to ensure top-notch performance and reliability. Kanak Fittings is dedicated to delivering cost-effective and innovative solutions, making it a go-to partner for industrial piping systems in the region.
| Size | : | 1/2″NB TO 4″NB IN |
| Standard | : | ASTM A182 / ASME SA182 |
| Dimensions | : | ANSI/ASME B16.11 & BS3799, etc. |
| Grade | : | UNS S31803, S32205, S2205, S32550, S32750, S32760. |
| Class | : | 2000LBS, 3000LBS, 6000LBS, 9000LBS, etc. |
Duplex Steel UNS S32205 is a high-performance alloy made up of chromium (22%), molybdenum (3%), and nickel (5-6%), along with nitrogen, which provides exceptional strength and resistance to corrosion. These forged fittings boast impressive mechanical properties, including high tensile and yield strength, excellent fatigue resistance, and remarkable toughness. They excel in extreme temperatures and are resistant to pitting, crevice corrosion, and stress corrosion cracking. Meeting standards like ASTM A182, they are perfect for high-pressure and high-temperature applications, ensuring long-lasting reliability in tough environments.
| UNS S31803 | Ni | Cr | Mo | Mn | Si | C | N | S | P | Fe |
| min | 4.5 | 22.0 | 3.0 | – | – | – | 0.14 | – | – | – |
| max | 6.5 | 23.0 | 3.5 | 2.0 | 1.0 | 0.03 | 0.2 | 0.02 | 0.03 | Balance |
| Grade | S31803 |
| Density (g/cm 3) | 7.805 |
| Density (lb/in 3) | 0.285 |
| Melting Point (°C) | 1420 – 1465 |
| Melting Point (°F) | 2588 – 2669; |
Kanak Fittings is a leading supplier of Duplex Steel UNS S32205 Forged Fittings in Dubai, UAE. We offer an extensive range of Duplex Steel UNS S32205 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Duplex Steel UNS S32205 Forged Fittings from Kanak Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Duplex Steel UNS S32205 Forged Fittings offer numerous advantages, including superior corrosion resistance, particularly in chloride environments, making them ideal for marine, chemical, and oil and gas industries. Their unique duplex microstructure combines the best of both austenitic and ferritic steels, providing high strength and excellent resistance to stress corrosion cracking. These fittings also offer enhanced fatigue resistance, high toughness, and excellent weldability, ensuring reliability and ease of installation. With impressive mechanical properties, Duplex Steel UNS S32205 Forged Fittings are perfect for high-pressure, high-temperature applications, delivering long-term durability and performance.
Yes, custom sizes for Duplex Steel UNS S32205 Forged Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.
| STANDARD | UNS | |
| Duplex Steel Forged Fittings | S31803 / S32205 |
| DN-NPT | MAJOR DIAMETER MM | TAPPING /DRILL SIZE MM | TPI | PITCH MM |
|---|---|---|---|---|
| 1/16″ | 7.895 | 6.00 | 27 | 0.941 |
| 1/8″ | 10.242 | 8.25 | 27 | 0.941 |
| 1/4″ | 13.616 | 10.70 | 18 | 1.411 |
| 3/8″ | 17.055 | 14.10 | 18 | 1.411 |
| 1/2″ | 21.223 | 17.40 | 14 | 1.814 |
| 3/4″ | 26.568 | 22.60 | 14 | 1.814 |
| 1″ | 33.228 | 28.50 | 11.5 | 2.209 |
| 1¼” | 41.985 | 37.00 | 11.5 | 2.209 |
| 1½” | 48.054 | 43.50 | 11.5 | 2.209 |
| 2″ | 60.092 | 55.00 | 11.5 | 2.209 |
| 2½” | 72.699 | 65.50 | 8 | 3.175 |
| 3″ | 88.608 | 81.50 | 8 | 3.175 |
| 3½” | 101.316 | 94.30 | 8 | 3.175 |
| 4″ | 113.973 | 107.00 | 8 | 3.175 |
| 5″ | 141.300 | 134.384 | 8 | 3.175 |
| 6″ | 168.275 | 161.191 | 8 | 3.175 |
| 8″ | 219.075 | 211.673 | 8 | 3.175 |
| 10″ | 273.050 | 265.311 | 8 | 3.175 |
| 12″ | 323.850 | 315.793 | 8 | 3.175 |
| Description | Class Designation | ||
|---|---|---|---|
| 3000 | 6000 | 9000 | |
| Elbows 45 and 90 degrees, Tees, Crosses, Couplings, Half-Couplings, End or Pipe Caps | 1/2 – 4 | 1/2 – 2 | 1/2 – 2 |
| 1/2 – 4 | 1/2 – 2 | 1/2 – 2 | |
| 1/2 – 4 | 1/2 – 2 | 1/2 – 2 | |
| Pipe Size by Wall Thickness | SCH 80 / XS | SCH 160 | XXS |
Duplex Steel UNS S32205 Forged Fittings are extensively used across various industries thanks to their outstanding corrosion resistance and mechanical strength. They find common applications in oil and gas pipelines, chemical processing plants, marine environments, and water treatment facilities. These fittings are particularly suited for handling aggressive chemicals, seawater, and other corrosive fluids, ensuring efficiency and longevity in systems. Their ability to endure high pressures and temperatures makes them essential in heat exchangers, pressure vessels, and structural applications, delivering reliable and cost-effective performance in demanding industrial settings.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
