Hastelloy Buttweld Fittings Manufacturer and Supplier in Dubai, UAE

Kanak Fittings stands out as a top-notch manufacturer and supplier of high-quality Hastelloy Buttweld Fittings in Dubai, UAE. Known for their commitment to quality and precision, the company offers a wide array of buttweld fittings that adhere to international standards like ASTM and ASME. These fittings are crafted to endure tough environments, making them perfect for critical sectors such as chemical processing, marine, and aerospace. With advanced manufacturing techniques and strict quality control, Kanak Fittings has built a reputation as a reliable partner for durable piping solutions.

Hastelloy Buttweld Fittings Manufacturer UAE, Hastelloy Alloy Buttweld Pipe Fittings Sharjah, Hastelloy Buttweld Pipe Fittings Dubai, Hastelloy Pipe Union Fitting Abu Dhabi, Hastelloy Pipe Fitting Size Chart Jebel Ali, Hastelloy Pipe Fittings Dealer Al Ain, Hastelloy Buttweld Fittings Suppliers Ajman, Hastelloy Alloy Pipe Fittings Suppliers in Dubai, UAE.

Hastelloy Buttweld Fittings Specification

Standards	ASTM B366 / ASME SB366
Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Size	Seamless Butt Weld Fittings : 1/2″ – 10″ Welded Butt Weld Fittings : 1/2″ – 48″
Type	Seamless / Welded / Fabricated
Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Hastelloy Buttweld Fittings are made from nickel-molybdenum-chromium alloys, enhanced with iron and cobalt to boost performance. This unique blend gives them outstanding resistance to pitting, stress corrosion cracking, and oxidation. They boast impressive mechanical properties, including high tensile and yield strength, toughness, and durability even in extreme conditions. Their ability to maintain structural integrity at high temperatures and in corrosive environments makes them perfect for critical applications. Plus, they meet international standards, ensuring dependable performance in demanding situations.

Manufacturing Standards of Hastelloy Buttweld Fittings

ASME B16.9 ASTM B366 Hastelloy Fittings	Factory-Made Wrought Buttwelding Fittings	Long Radius Elbows, Long Radius Reducing Elbows, Long Radius Returns, Short Radius Elbows, Short Radius 180-deg Rerurns, 3D elbows, Straight Tees, Straight Crosses, Reducing Outlet Tees, Reducing Outlet Crosses, Lap Joint Stub Ends, Caps, Reducers
ASME B16.28		Short Radius Elbows, Short Radius 180-deg Returns
MSS SP43	Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications	Long Radius Elbows, Straight and Reducing-on-the-Outlet Tees, Lap Joint Stub ends, caps, long radius 180 Degree returns, concentric reducers, eccentric reducers
MSS SP75		Long Radius Elbows, 3R elbows, straight tees, reducing outlet tees, caps, reducers

Hastelloy Seamless Pipe Fittings UAE, Hastelloy 1.5d Pipe Bend Sharjah, ASME SB366 Hastelloy Long Stub Dubai, Hastelloy 3D Bend Abu Dhabi, Hastelloy Welded Buttweld Fittings Jebel Ali, ASTM B366 Hastelloy Alloy 90 degree Elbow Exporters and Suppliers in Al Ain, Supplier of Hastelloy 45 degree Elbow Ajman, ASTM B366 Hastelloy Short Radius Elbow Supplier UAE, Hastelloy Cross Exporter in Dubai, UAE.

Largest Hastelloy Buttweld Fittings Supplier in Dubai, UAE

Kanak Fittings is a leading supplier of Hastelloy Buttweld Fittings in Dubai, UAE. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Hastelloy Buttweld Fittings Dimensions Standard

All Fittings				90°and 45° Ells and Tees	Reducers and Lap Joint Stub	Caps	180° Returns			Angularity Tol
Nominal Pipe Plane Size (NPS)	Outside⁽¹⁾ Diameter at Bevel	Inside⁽¹⁾ Diameter at End	Wall⁽²⁾ Thickness	Centre-to- End Dimension A,B,C,M	Overall Length L	Overall Length E	Centre-to- Centre Dimension O	Back-to- Face Dimension K	Alignment at Ends U	Nominal Pipe SIze	Off Angle Q	Off Angle P
1/2 TO 2-1/2	+1/16	±1/32	Not less than 87-1/2% of Normal Thickness	±1/16	±1/16	±1/8	±1/4	±1/4	±1/32	12 to 4	1/32	1/16
	-1/32									5 to 8	1/16	1/8
3 TO 3-1/2	±1/16	±1/16		±1/16	±1/16	±1/8	±1/4	±1/4	±1/32	10 to 12	3/32	3/16
4	±1/16	±1/16		±1/16	±1/16	±1/8	±1/4	±1/4	±1/32	14 to 16	3/32	1/4
5 TO 8	+1/32	±1/16		±1/16	±1/16	±1/4	±1/4	±1/4	±1/32	18 to 24	1/8	3/8
	-1/16
10 TO 18	+1/16	±1/8		±3/32	±3/32	±1/4	±3/8	±1/4	±1/16	All dimensions are in inches
	-1/8
20 TO 24	+1/4	±3/32		±3/32	±3/32	±1/4	±3/8	±1/4	±1/16
	-3/32

Why Choose Hastelloy Buttweld Fittings from Kanak Fittings?

Hastelloy Buttweld Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Hastelloy Butt weld Pipe Fittings UAE, Hastelloy 10d Pipe Bend Sharjah, ANSI B16.9 Hastelloy Welded Buttweld Fittings Dubai, Hastelloy 5D Bend Abu Dhabi, Hastelloy Alloy End Cap Jebel Ali, Hastelloy 180 Deg bend Al Ain, Hastelloy Alloy Reducer Ajman, Hastelloy Alloy Equal Tee UAE, ASME B16.9 Hastelloy Long Stub End Exporter Sharjah, Hastelloy Alloy Pipe bend Supplier in Dubai, UAE.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Hastelloy buttweld fittings are widely used in industries requiring superior corrosion resistance and durability. They are essential in chemical processing plants for handling highly corrosive substances like acids and solvents. In the petrochemical industry, they are used for transporting hydrocarbons under extreme temperatures and pressures. These fittings are also employed in marine environments to resist saltwater corrosion, as well as in power generation, pharmaceuticals, and aerospace for their reliability in harsh conditions. Their versatility makes them ideal for critical piping systems in demanding applications.

Types of Hastelloy Buttweld Fittings

Are Custom Sizes Available for Hastelloy Buttweld Fittings?

Yes, custom sizes for Hastelloy Buttweld Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.

Hastelloy Buttweld Fittings Manufacturer UAE, Hastelloy Alloy Buttweld Pipe Fittings Sharjah, Hastelloy Buttweld Pipe Fittings Dubai, Hastelloy Pipe Union Fitting Abu Dhabi, Hastelloy Pipe Fitting Size Chart Jebel Ali, Hastelloy Pipe Fittings Dealer Al Ain, Hastelloy Buttweld Fittings Suppliers Ajman, Hastelloy Alloy Pipe Fittings Suppliers in Dubai, UAE.

Application Industry of Hastelloy Buttweld Fittings

Hastelloy Buttweld Fittings are extensively utilized in industries that demand exceptional corrosion resistance and mechanical strength. They’re particularly suited for chemical processing applications, where they can handle highly acidic and oxidizing conditions. These fittings are also widely used in marine engineering, power generation, and aerospace due to their resistance to seawater and high-temperature oxidation. Common uses include connecting pipes, changing flow directions, and ensuring leak-proof fluid transmission. Their robust design and remarkable durability make them essential in high-performance and safety-critical systems.
