Kanak Fittings has made a name for itself as a leading manufacturer and supplier of Hastelloy Forged Fittings in Dubai, UAE. We specialize in providing top-notch corrosion-resistant solutions tailored for the most aggressive chemical environments. Hastelloy, a family of corrosion-resistant metal alloys, is primarily made up of nickel, with varying amounts of molybdenum, iron, cobalt, and chromium depending on the specific grade—like Hastelloy C22, C276, or B2. Our extensive range of forged fittings includes elbows, tees, couplings, unions, plugs, and bushings, all crafted to meet international standards. We proudly support critical industries such as chemical processing, marine, oil & gas, and pharmaceuticals with our durable and precision-engineered products.
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Hastelloy C276, C22, C4, C2000, B2, B3, X Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
Hastelloy Forged Fittings are celebrated for their outstanding corrosion resistance across a wide array of harsh environments, including those with oxidizing and reducing agents. The typical compositions feature high nickel content (50–60%), molybdenum (15–22%), chromium (14–16%), and iron, depending on the alloy grade. These fittings boast impressive mechanical properties, with tensile strength reaching up to 790 MPa, yield strength around 355 MPa, and elongation of 40% or more. Hastelloy effectively resists pitting, crevice corrosion, and stress corrosion cracking, maintaining its integrity even under high pressure and elevated temperatures, making it perfect for highly corrosive process environments.
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| B2 | 0.02 max | 1.0 max | 0.1 max | 0.03 max | 1.0 max | Bal | 1.0 max | 2.0 max | 26 – 30 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| Hastelloy B2 | 9.2 g/cm3 | 1370 °C (2500 ºF ) | Psi – 1,10,000 , MPa – 760 | Psi – 51000 , MPa – 350 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
| Hastelloy C22 | 2.4602 | N06022 | NW 6022 | – | NiCr21Mo14W | – |
| Hastelloy B2 | 2.4617 | N10665 | – | – | – | – |
Kanak Fittings is a leading supplier of Hastelloy Forged Fittings in Dubai, UAE. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hastelloy Forged Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Hastelloy forged fittings offer several key advantages, making them ideal for demanding industrial applications. Their superior corrosion resistance, especially against acids, chlorine, and high-temperature environments, ensures long-lasting performance. These fittings also provide excellent strength, even in extreme conditions, and are resistant to stress corrosion cracking and pitting. With their ability to maintain mechanical properties at elevated temperatures, Hastelloy forged fittings are reliable in harsh chemical processing, aerospace, and power generation industries. Their durability and resilience reduce maintenance costs and improve the overall efficiency of critical systems.
Yes, custom sizes for Hastelloy Forged Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.
You’ll find Hastelloy Forged Fittings widely used in applications that demand resilience against harsh chemical conditions and extreme temperatures. They are commonly found in chemical reactors, heat exchangers, pressure vessels, and piping systems that handle strong acids like sulfuric, hydrochloric, nitric, and hydrofluoric acids. These fittings are also ideal for offshore and marine systems, pollution control equipment, and flue gas scrubbers. In the pharmaceutical and food industries, Hastelloy is prized for its purity and resistance to contamination. Renowned for their longevity, reliability, and versatility, Hastelloy forged fittings are truly the go-to choice for many applications.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
