Kanak Fittings stands out as a premier manufacturer and supplier of Inconel 625 Forged Fittings, proudly based in Dubai, UAE. The company has built a solid reputation for providing top-notch, high-performance forged components that serve a variety of industries, including aerospace, chemical processing, marine, oil and gas, and power generation. Inconel 625 Forged Fittings are designed to deliver exceptional strength, corrosion resistance, and durability, even in the harshest environments, where high temperatures and aggressive chemicals are the norm. Kanak Fittings is committed to ensuring that each fitting adheres to global industry standards, thanks to their advanced forging techniques and rigorous quality control measures. With a strong emphasis on precision, reliability, and customer satisfaction, they have earned the trust of clients both in the UAE and around the world.
| Standards | ASTM, ASME |
| Designation | B564, SB564 |
| Dimension Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Grade | Inconel 625 Forged Fittings. |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Types of Forged Fittings | Elbow, Tee, Union, Cross, Swage Nipples, Coupling, CAP, Plug, Bush. |
These Inconel 625 Forged Fittings are crafted from a nickel-chromium-molybdenum-niobium alloy, which provides remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking. The alloy boasts impressive mechanical properties, including a tensile strength of about 827 MPa and a yield strength of roughly 414 MPa, along with high fatigue and rupture resistance. It maintains its structural integrity across a wide temperature range, from cryogenic levels all the way up to 982°C. The forging process not only enhances its grain structure but also results in superior mechanical strength and reliability, even in the toughest conditions.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
Kanak Fittings is a leading supplier of Inconel 625 Forged Fittings in Dubai, UAE. We offer an extensive range of Inconel 625 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
Choose Inconel 625 Forged Fittings from Kanak Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Inconel 625 Forged Fittings offer exceptional advantages, including high strength, excellent corrosion resistance, and superior performance in extreme conditions. Their ability to resist pitting, crevice corrosion, and stress corrosion cracking makes them ideal for marine, chemical, and offshore applications. These fittings maintain mechanical integrity at elevated temperatures, providing outstanding thermal-fatigue and oxidation resistance. Inconel 625’s excellent weldability allows for ease of installation and customization. With their durability and resistance to harsh environments, these fittings deliver long-lasting, reliable solutions for industries such as aerospace, power generation, and petrochemical processing.
Yes, custom sizes for Inconel 625 Forged Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae
Inconel 625 Forged Fittings find their place in various applications that demand high strength and corrosion resistance under extreme conditions. In the aerospace industry, they are essential for jet engines, exhaust systems, and structural components. The oil and gas sector depends on them for offshore platforms, subsea equipment, and environments with sour gas. Chemical processing facilities utilize them in heat exchangers, reactor vessels, and systems for handling acids. Additionally, they play a crucial role in marine engineering, pollution control equipment, and nuclear power systems, where reliability and long-term performance are vital in challenging operating conditions.
