Kanak Fittings has made a name for itself as a trusted manufacturer and supplier of Monel Buttweld Fittings right here in Dubai, UAE. We specialize in providing corrosion-resistant and high-performance piping components that are perfect for tough industrial applications. Crafted from top-notch nickel-copper alloys, our Monel Buttweld Fittings meet international standards like ASTM B366. These fittings are designed to thrive in harsh conditions, whether it’s seawater, acids, or high-temperature processes. With a strong presence in industries such as marine, chemical processing, oil and gas, and power generation, Kanak Fittings is well-regarded throughout the UAE and the Middle East for our reliable products, outstanding quality, and prompt customer service.
Specifications : ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″
Type : Seamless / Welded / Fabricated
Schedule : Sch 5 TO Sch XXS.
Thickness : 20 Swg., 18 Swg., 16 Swg., 14 Swg., 12 Swg., 10 Swg., & Sch. 10, Sch. 40, Sch. 80 etc.
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
When it comes to Monel Buttweld Fittings, we typically use alloys like Monel 400 and Monel K500, which are celebrated for their remarkable corrosion resistance, particularly in seawater and acidic settings. The typical composition features Nickel (63–70%) and Copper (20–29%), along with trace amounts of Iron and Manganese. Monel 400 boasts a tensile strength of about 550–620 MPa, while Monel K500 takes it up a notch with even greater strength thanks to its age-hardening properties. These fittings are not only highly ductile and easy to weld, but they also perform exceptionally well in a range of temperatures, from sub-zero to elevated levels, making them perfect for high-pressure and corrosive environments.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
Kanak Fittings is a leading supplier of Monel Buttweld Fittings in Dubai, UAE. We offer an extensive range of Monel Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| Monel | 2.4375 | N05500 | – | – | – | – | – |
Choose Monel Buttweld Fittings from Kanak Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Monel Buttweld Fittings offer numerous advantages, including exceptional corrosion resistance, particularly in seawater, acidic, and alkaline environments. They are highly durable, resisting pitting, crevice corrosion, and stress corrosion cracking, which ensures reliable performance in harsh conditions. These fittings also retain their strength and mechanical properties at elevated temperatures, making them ideal for high-pressure and high-temperature applications. Monel Buttweld Fittings are also known for their excellent weldability, machinability, and long-term reliability. Their versatility and ability to withstand aggressive environments make them a preferred choice for marine, chemical, and industrial applications.
Yes, custom sizes for Monel Buttweld Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae
Monel Buttweld Fittings find their place in various industries that demand outstanding corrosion resistance and robust mechanical properties. You’ll often see them in applications like heat exchangers, offshore piping systems, pump and valve components, condensers, and chemical processing lines. They shine particularly in marine settings and in systems that deal with sulfuric, hydrofluoric, or hydrochloric acids. With Monel fittings, you can count on leak-proof and durable connections in your pipeline systems, which is crucial for operations where material reliability and longevity are non-negotiable. Their ability to resist stress-corrosion cracking and handle thermal extremes makes them a top choice for demanding applications.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
