Kanak Fittings is a reputable manufacturer and supplier of high-quality Incoloy 825 Forged Fittings based in Dubai, UAE. We specialize in providing corrosion-resistant solutions tailored for tough industrial settings. Incoloy 825 is a unique alloy made from nickel, iron, and chromium, enhanced with molybdenum, copper, and titanium, which gives it remarkable resistance to acid attacks, stress corrosion cracking, and pitting. Our extensive range of forged fittings includes elbows, tees, couplings, unions, and plugs, all crafted to meet international standards. With a strong commitment to quality, precision, and prompt service, Kanak Fittings caters to vital industries such as chemical processing, oil & gas, power generation, and marine engineering across the UAE and beyond.
| ASTM B564 Incoloy Alloy 825 Forged Fittings Specification | |
|---|---|
| Specifications | ASTM B564 / ASME SB564 |
| Standards | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8″ NB to 4″ NB (Socketweld & Screwed-Threaded) |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT |
| Gr.825 Incoloy Alloy Forged Pipe Fittings Chemical Composition | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Grade | Ni | C | Fe | Si | Mn | S | Al | Ti | Cu | Cr | Mb |
| Incoloy 825 | 38.0 – 46.0 | 0.05 max | 22.0 min | 0.5 max | 1.0 max | 0.03 max | 0.2 max | 0.6 – 1.2 | 1.5 – 3.0 | 19.5 – 23.5 | 2.5 – 3.5 |
| Incoloy 825 Forged Fittings Mechanical Properties | |||||
|---|---|---|---|---|---|
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000, MPa -550 | Psi – 32,000, MPa – 220 | 30 % |
| Incoloy ASTM B564 Forged Fittings Equivalent Grades | ||||||||
|---|---|---|---|---|---|---|---|---|
| STANDARD | UNS | WNR NO. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 825 | N08825 | 2.4858 | NFE30C20DUM | NiCr21Mo | NCF 825 | NA 16 | ЭП703 | XH38BT |
Incoloy 825 Forged Fittings consist of about 38–46% nickel, 19.5–23.5% iron, 19.5–23.5% chromium, 2.5–3.5% molybdenum, 1.5–3% copper, and are stabilized with titanium (0.6–1.2%). These fittings are known for their outstanding resistance to sulfuric and phosphoric acids, as well as to both oxidizing and reducing environments. Their mechanical properties include a minimum tensile strength of 690 MPa, a yield strength of 310 MPa, and an elongation of at least 30%. Incoloy 825 also maintains impressive toughness and strength at both room and elevated temperatures, making it perfect for highly corrosive and variable service conditions.
Kanak Fittings is a leading supplier of Incoloy 825 Forged Fittings in Dubai, UAE. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy 825 Forged Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy 825 forged fittings offer outstanding resistance to corrosion, especially in acidic and oxidizing environments, making them ideal for chemical processing and marine applications. Their high nickel content prevents stress-corrosion cracking, while molybdenum and copper enhance resistance to pitting and crevice corrosion. These fittings maintain excellent mechanical strength and stability across a broad temperature range. They are also highly durable and versatile, supporting easy fabrication and welding. Reliable and long-lasting, Incoloy 825 forged fittings are perfect for demanding industries like oil and gas, pollution control, and power generation systems.
Yes, custom sizes for Incoloy 825 Forged Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae
Incoloy 825 Forged Fittings are commonly utilized in sectors where robust corrosion resistance is crucial, especially in chemical processing, acid production, pollution control, and marine applications. These fittings are particularly well-suited for piping systems that handle sulfuric, phosphoric, nitric, and organic acids. They also find applications in oil and gas refineries, nuclear fuel reprocessing, and offshore platforms, where resistance to stress corrosion cracking and crevice corrosion is vital. The durability, weldability, and resistance to both oxidizing and reducing media of Incoloy 825 make it a dependable choice for aggressive and high-temperature service environments.
