Kanak Fittings has earned a solid reputation as a reliable manufacturer and supplier of top-notch Incoloy Buttweld Fittings in Dubai, UAE. We pride ourselves on delivering high-performance piping solutions tailored for industries that require exceptional strength and resistance to corrosion. With a focus on nickel-based alloys, our Incoloy fittings adhere to international quality standards, making them perfect for extreme conditions involving high temperatures and aggressive chemicals. You’ll find our Incoloy Buttweld Fittings widely utilized in sectors like oil and gas, petrochemicals, power generation, and marine engineering. Thanks to our commitment to precision manufacturing, timely delivery, and deep technical expertise, Kanak Fittings has become the go-to partner for dependable alloy piping components throughout the UAE and the Middle East.
| Specifications | : | ASTM B366 / ASME SB366 |
| Size | : | Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″ |
| Standards | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | : | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | : | Seamless / Welded / Fabricated |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
Our Incoloy Buttweld Fittings are crafted from nickel-iron-chromium alloys, including Incoloy 800, 800H, 825, and others, which provide outstanding resistance to oxidation, carburization, and corrosion in high-temperature settings. Typically, their composition features Nickel (30–46%), Chromium (19–23%), Iron (the balance), along with trace amounts of Molybdenum, Copper, and Titanium, depending on the specific grade. These fittings boast impressive tensile strength (≥500 MPa), yield strength (≥200 MPa), and good ductility. Incoloy alloys are designed to maintain their structural integrity even in acidic and high-temperature environments, making these buttweld fittings perfect for operations that are both corrosive and heat-intensive.
Kanak Fittings is a leading supplier of Incoloy Buttweld Pipe Fittings in Dubai, UAE. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy Pipe Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy Buttweld Fittings offer numerous advantages, making them a preferred choice across industries. Their excellent corrosion resistance ensures durability in harsh environments, including high temperatures and chemical exposure. These fittings provide superior mechanical strength, reducing the risk of failure under pressure. The seamless construction enhances flow efficiency and eliminates weak points, ensuring long-term reliability. Incoloy’s resistance to oxidation and stress-corrosion cracking adds to its versatility, making it ideal for marine, chemical, and power industries. Easy to weld and install, these fittings also ensure leak-proof and robust connections.
Yes, custom sizes for Incoloy Pipe Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.
Incoloy Buttweld Fittings find their place in a wide range of high-performance applications across industries that operate in challenging chemical and thermal conditions. They are essential in chemical processing plants, offshore oil and gas platforms, power generation facilities, marine systems, and even nuclear reactors. These fittings are particularly suited for piping systems that transport acids, seawater, high-temperature steam, and other corrosive materials. Commonly found in heat exchangers, reactors, condensers, and pressure vessels, Incoloy fittings guarantee long-lasting reliability, corrosion resistance, and mechanical strength, even when faced with fluctuating thermal and chemical challenges.
