Inconel 601 Pipe Fittings Manufacturer and Supplier in Dubai, UAE

Kanak Fittings stands out as a top-notch manufacturer and supplier of Inconel 601 Pipe Fittings right here in Dubai, UAE. We specialize in providing dependable solutions for industries that require exceptional resistance to high temperatures and oxidation. Inconel 601 is a nickel-chromium alloy known for its remarkable metallurgical stability and mechanical strength, even in extreme thermal conditions. Our extensive range of pipe fittings includes elbows, tees, reducers, and caps, all designed to meet international standards for high-temperature and corrosive environments. With a strong commitment to quality, precision, and timely delivery, Kanak Fittings proudly serves clients across various sectors, including chemical processing, thermal power, petrochemical, and aerospace applications.

Inconel 601 Pipe Fittings In UAE, 601 Inconel Alloy Butt weld Pipe Fittings Sharjah, Inconel® 601 Pipe Fittings Suppliers Dubai, Alloy 601 Buttweld Fittings Abu Dhabi, ASTM B366 Inconel 601 Pipe Elbow Jebel Ali, 601 Inconel Alloy Buttweld Tee Dealer Al Ain, Inconel Grade 601 Butt weld Pipe Fittings Stockists Ajman, Distributors of Inconel® Alloy 601 ASME SB366 Buttweld Reducer in Dubai, UAE.

Inconel 601 Pipe Fittings Specification

Specifications ASTM B366 / ASME SB366

Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79

Size 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)

Type Seamless / Welded / Fabricated

Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Grade 601 UNS (N06601), DIN (2.4851)

When it comes to composition, Inconel 601 Pipe Fittings are made up of about 58–63% nickel, 21–25% chromium, along with trace amounts of aluminum, iron, and carbon. This unique blend provides outstanding resistance to oxidation, even at temperatures soaring above 1000°C. The alloy boasts impressive mechanical properties, featuring a tensile strength of around 550–690 MPa, yield strength of approximately 205–310 MPa, and an elongation of about 30%. It effectively resists spalling, scaling, and carburization in harsh environments. Plus, Inconel 601 is known for its good weldability and structural stability during extended thermal exposure, making it a perfect fit for demanding industrial applications.

Inconel 601 Pipe Fittings Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr
Inconel 601	0.10 max	1.0 max	0.5 max	0.015 max	1.0 max	Balance	58.0 – 63.0	21.0 – 25.0

Inconel 601 Pipe Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.1 g/cm3	1411 °C (2571 °F)	Psi – 80,000 , MPa – 550	Psi – 30,000 , MPa – 205	30 %

601 Inconel Welded Pipe Fittings Suppliers In UAE, UNS N06601 Nickel Alloy Butt weld Seamless Pipe Fitting Sharjah, 601 Inconel® 45°/90°/180° Butt weld Elbow Dubai, Nickelvac® 601 Pipe Fittings Abu Dhabi, Alloy 601 Equal Tee Wholesaler Jebel Ali, ASME B16.28 601 Inconel Alloy Butt weld Reducing Tee Al Ain, 601 Inconel® Unequal Cross Exporters Ajman, 601 Alloy ANSI B16.9 Short & Long Radius Elbow In Dubai, UAE.

Largest Inconel 601 Pipe Fittings Supplier in Dubai, UAE

Kanak Fittings is a leading supplier of Inconel 601 Pipe Fittings in Dubai, UAE. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Inconel 601 Pipe Fittings Equivalent Grade

STANDARD	UNS	WNR.	AFNOR	EN	JIS	BS	GOST	OR
Alloy 601	N06601	2.4851	NiCr23Fe	NiCr15Fe	NCF 601	NA 49	XH60BT	ЭИ868

Why Choose Inconel 601 Pipe Fittings from Kanak Fittings?

Inconel 601 Pipe Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Werkstoff No 2.4851 Inconel® Butt weld Eccentric Reducer Traders In UAE, 601 Nickel Alloy Concentric Reducer Sharjah, Ferrochronin® 601 Pipe Fittings Dubai, Inconel Pipe Fittings Abu Dhabi, Inconel 601 Seamless Pipe Fittings Jebel Ali, MSS SP-79 Inconel Alloy 601 End Pipe Cap Suppliers In Al Ain, Inconel 601 MSS-SP-43 Buttweld Swage Nipple Ajman, Inconel® Alloy JIS NCF 601 Stub Ends Exporters In Dubai, UAE.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Inconel 601 Pipe Fittings offer numerous advantages, making them ideal for demanding applications. They excel in high-temperature resistance, maintaining strength and stability up to 1200°C. Their exceptional oxidation and corrosion resistance ensures durability in harsh environments, including chemical processing and thermal cycling. The addition of aluminum enhances their protective oxide layer, resisting spalling and scaling. These fittings also provide excellent mechanical strength and creep resistance under stress, along with good weldability. Their versatility and reliability make them indispensable in power generation, aerospace, and heat treatment industries.

Inconel 601 Pipe Fittings Size Chart

Product range and theoretical weights (kg)
DN	Schedule 10S			Schedule 40S			Schedule 80S
DN	90° Elbow	45° Elbow	Equal tee	90° Elbow	45° Elbow	Equal tee	90° Elbow	45° Elbow	Equal tee
8	0.02	0.01	0.03	0.03	0.02	0.06	0.04	0.03	0.07
10	0.03	0.02	0.05	0.03	0.02	0.03	0.06	0.04	0.09
15	0.06	0.03	0.09	0.08	0.04	0.10	0.10	0.05	0.14
20	0.07	0.03	0.13	0.08	0.04	0.17	0.11	0.05	0.20
25	0.14	0.08	0.28	0.15	0.11	0.29	0.22	0.14	0.38
32	0.23	0.11	0.49	0.26	0.17	0.59	0.40	0.23	0.68
40	0.30	0.17	0.68	0.40	0.23	0.86	0.51	0.29	1.02
50	0.50	0.25	0.85	0.70	0.4	1.28	0.91	0.59	1.59
65	0.85	0.48	1.41	1.40	0.77	2.19	1.81	0.99	3.13
80	1.25	0.63	1.77	2.20	1.08	3.31	2.97	1.50	4.45
90	1.70	0.75	2.67	2.83	1.42	4.08	4.00	2.00	5.44
100	2.10	1.08	3.46	4.47	2.09	5.27	6.18	2.81	7.71
150	5.45	2.72	8.07	10.89	5.44	10.99	16.32	8.16	13.61
200	10.20	5.33	15.65	21.54	10.77	20.91	33.11	16.56	28.12
250	18.15	9.75	26.46	38.56	19.27	35.38	51.71	25.86	49.90
300	25.80	13.62	39.46	59.42	29.71	62.14	79.38	39.69	83.91

Types of Inconel 601 Pipe Fittings

Are Custom Sizes Available for Inconel 601 Pipe Fittings?

Yes, custom sizes for Inconel 601 Pipe Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.

Werkstoff No 2.4851 Inconel® Butt weld Eccentric Reducer Traders In UAE, 601 Nickel Alloy Concentric Reducer Sharjah, Ferrochronin® 601 Pipe Fittings Dubai, Inconel Pipe Fittings Abu Dhabi, Inconel 601 Seamless Pipe Fittings Jebel Ali, MSS SP-79 Inconel Alloy 601 End Pipe Cap Suppliers In Al Ain, Inconel 601 MSS-SP-43 Buttweld Swage Nipple Ajman, Inconel® Alloy JIS NCF 601 Stub Ends Exporters In Dubai, UAE.

Application Industry of Inconel 601 Pipe Fittings

Inconel 601 Pipe Fittings find their place in industries that need robust resistance to high-temperature oxidation and thermal cycling. They are commonly used in heat treating equipment, furnace components, petrochemical processing, and exhaust systems. The alloy’s stellar performance in both oxidizing and neutral environments makes it ideal for steam reformers, radiant tubes, and catalyst support systems. Additionally, it’s utilized in aerospace and marine settings where high mechanical strength and corrosion resistance are crucial. With Inconel 601 fittings, you can count on long-lasting performance and reliability, even in systems that face harsh operating conditions and fluctuating temperatures.
