Kanak Fittings stands out as a top-notch manufacturer and supplier of high-quality Inconel 625 Pipe Fittings right here in Dubai, UAE. We specialize in providing advanced piping solutions tailored for the toughest industrial environments. Our fittings are crafted from premium nickel-chromium-molybdenum alloys, ensuring they deliver exceptional strength, corrosion resistance, and durability even in extreme conditions. Adhering to international standards like ASTM B366, our Inconel 625 Pipe Fittings are perfect for critical operations across offshore, chemical, marine, and aerospace sectors. With a reputation for precision manufacturing and timely delivery, Kanak Fittings has become a trusted partner for reliable alloy fittings throughout the UAE and the Middle East.
Standard :ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Type : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Our Inconel 625 Pipe Fittings are made from a nickel-based superalloy that includes at least 58% Nickel, 20–23% Chromium, 8–10% Molybdenum, 3.15–4.15% Niobium, along with trace amounts of Iron and other elements. This unique blend gives them remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking caused by chlorides. Inconel 625 boasts impressive mechanical properties, with a tensile strength exceeding 827 MPa and a yield strength around 414 MPa, along with outstanding fatigue resistance. Its ability to maintain strength at high temperatures and resist oxidation makes it ideal for harsh environments
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 705 | 42.5 % |
Kanak Fittings is a leading supplier of Inconel 625 Pipe Fittings in Dubai, UAE. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Pressure-Temperature ratings for Inconel 625 Pipe Fittings (psig) | |||||
|---|---|---|---|---|---|
| Temperature Ratings | Pressure Class | ||||
| 150 | 300 | ||||
| 1/4 – 1 inch. | 1 1/4 – 2 inch. | 2 1/2 – 3 inch. | |||
| (oF) | (oC) | ||||
| -20 to 150 | -29 to 66 | 300 | 2000 | 1500 | 1000 |
| 200 | 93 | 265 | 1785 | 1350 | 910 |
| 250 | 121 | 225 | 1575 | 1200 | 825 |
| 300 | 149 | 185 | 1360 | 1050 | 735 |
| 350 | 177 | 150 | 1150 | 900 | 650 |
| 400 | 204 | – | 935 | 750 | 560 |
| 450 | 232 | – | 725 | 600 | 475 |
| 500 | 260 | – | 510 | 450 | 385 |
| 550 | 288 | – | 300 | 300 | 300 |
Inconel 625 Pipe Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| DN (Normal Pipe Size) For ASME B16.9 | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Inconel 625 Pipe Fittings offer superior performance in challenging environments. Their outstanding corrosion and oxidation resistance make them ideal for marine, chemical, and aerospace industries. They withstand extreme temperatures, from cryogenic to 980°C, maintaining mechanical integrity. High tensile and yield strength eliminate the need for additional heat treatments. These fittings resist pitting, crevice corrosion, and stress-corrosion cracking, ensuring durability in acidic and saltwater conditions. Additionally, their excellent weldability and fabricability simplify installation, making them a reliable and cost-effective choice for high-performance applications across diverse industries.
Yes, custom sizes for Inconel 625 Pipe Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.
Inconel 625 Pipe Fittings find their place in industries that require top performance under extreme conditions. Common applications include offshore oil and gas pipelines, marine systems, heat exchangers, chemical processing plants, power generation equipment, and aerospace exhaust systems. These fittings are particularly well-suited for environments exposed to seawater, high temperatures, acidic solutions, and strong oxidizers. Their excellent weldability and long service life help minimize maintenance needs and boost operational reliability. Thanks to its unique properties, Inconel 625 is the go-to choice for safety-critical and corrosion-sensitive applications in highly engineered and demanding environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
