Incoloy 825 Buttweld Fittings Manufacturer and Supplier in Dubai, UAE

Kanak Fittings is a reliable manufacturer and supplier of Incoloy 825 Buttweld Fittings based in Dubai, UAE. We specialize in providing corrosion-resistant solutions tailored for demanding industrial applications. Incoloy 825 is a unique nickel-iron-chromium alloy that includes molybdenum, copper, and titanium, crafted to deliver outstanding resistance against a variety of corrosive environments, such as sulfuric and phosphoric acids. Our extensive range of buttweld fittings includes elbows, tees, reducers, and caps, all designed to meet international quality standards. With a commitment to reliability, precision, and timely delivery, Kanak Fittings caters to industries like chemical processing, marine, oil & gas, and power generation throughout the UAE and beyond.

ANSI B16.9 Incoloy 825 Welded Buttweld Fittings UAE, Incoloy UNS N08800 Seamless Pipe Fittings Sharjah, Incoloy 3d Pipe Bend Dubai, Alloy 825 Short Radius Elbow Supplier Abu Dhabi, Incoloy 825 Pipe Fittings Jebel Ali, 825 Incoloy® Alloy Welded Pipe Fittings Dealer Al Ain, 825 Incoloy Alloy End Cap Ajman, ASTM B366 825 Incoloy Alloy 90 degree Elbow Exporters and Suppliers in UAE, Incoloy 1.5d Pipe Bend Sharjah, 825 Incoloy Alloy End Cap Dubai, Incoloy WERKSTOFF NR1.4958 Cross Exporter in Al Ain.

Incoloy 825 Buttweld Fittings Specification

Grade	Incoloy Alloy 825 / UNS N08825
Standard	ASTM B366, ASME SB366
Dimensions	ASME B16.28, ASME/ANSI B16.9, MSS-SP-43
Incoloy 825 Seamless Fittings	1/2″ NB – 10″ NB
Incoloy 825 Welded Fittings	1/2″ NB – 48″ NB
Form	90 Elbow, 45 Elbow, Long Radius Elbow, Short Radius Elbow, Concentric Reducer, Eccentric Reducer, Equal Tee, Unequal Tee, Lateral Tee, Cross, Bends 1.5d, 3d, 5d, 10d, U bend, 180 Deg Bend, Short Stub End, Long stub end, End Cap, Dish Cap
Schedule	SCH 5 To SCH XXS
Wall Thickness	from 2 to 40 mm
Type	Seamless / Welded / Fabricated

Incoloy 825 Buttweld Fittings Chemical Composition

Ni	Fe	C	Mn	Si	Mb	Cu	Cr	Al	Ti	S
38.0 – 46.0	22.0 min	0.05 max	1.0 max	0.5 max	2.5 – 3.5	1.5 – 3.0	19.5 – 23.5	0.2 max	0.6 – 1.2	0.015 max

Incoloy 825 Buttweld Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.14 g/cm3	1400 °C (2550 °F)	Psi – 80,000 , MPa -550	Psi – 32,000 , MPa – 220	30 %

Incoloy 825 Buttweld Fittings consist of about 38–46% nickel, 19.5–23.5% iron, 19.5–23.5% chromium, 2.5–3.5% molybdenum, 1.5–3% copper, and 0.6–1.2% titanium. This well-balanced composition ensures excellent resistance to both oxidizing and reducing acids, as well as protection against stress corrosion cracking, pitting, and crevice corrosion. The mechanical properties boast a minimum tensile strength of 690 MPa, a yield strength of 310 MPa, and an elongation of at least 30%. Incoloy 825 also maintains good strength and stability across a wide temperature range, making it suitable for various aggressive environments.

825 Incoloy Alloy End Cap UAE, Incoloy® Alloy 825 180 Deg bend Sharjah, Incoloy Alloy 825 Pipe Bend Dubai, Jis Ncf 825 Pipe Fittings Abu Dhabi, Incoloy Alloy 825 Stub Ends Jebel Ali, Incoloy 825 Pipe End Cap Al Ain, 825 Incoloy Alloy End Cap Ajman, Incoloy® Alloy 825 Equal Tee Dubai, Ansi B16.9 800h Incoloy 45 / 90 / 180 Deg. Reducing Elbow UAE, Incoloy 825 Pipe Elbow Dubai, Supplier of Incoloy 825 45 degree Elbow UAE, Incoloy 10d Pipe Bend Abu Dhabi, 825 Incoloy Reducer, Incoloy® Alloy 825 Pipe bend Supplier in UAE.

Largest Incoloy 825 Buttweld Fittings Supplier in Dubai, UAE

Kanak Fittings is a leading supplier of Incoloy 825 Buttweld Fittings in Dubai, UAE. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose Incoloy 825 Buttweld Fittings from Kanak Fittings?

Incoloy 825 Buttweld Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

ANSI B16.9 Incoloy 825 Welded Buttweld Fittings UAE, Incoloy UNS N08800 Seamless Pipe Fittings Sharjah, Incoloy 3d Pipe Bend Dubai, Alloy 825 Short Radius Elbow Supplier Abu Dhabi, Incoloy 825 Pipe Fittings Jebel Ali, 825 Incoloy® Alloy Welded Pipe Fittings Dealer Al Ain, 825 Incoloy Alloy End Cap Ajman, ASTM B366 825 Incoloy Alloy 90 degree Elbow Exporters and Suppliers in UAE, Incoloy 1.5d Pipe Bend Sharjah, 825 Incoloy Alloy End Cap Dubai, Incoloy WERKSTOFF NR1.4958 Cross Exporter in Al Ain.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Incoloy 825 buttweld fittings offer several key advantages. Their exceptional resistance to a wide range of corrosive environments, including acids, seawater, and gases, makes them ideal for harsh industrial conditions. The alloy’s high nickel and chromium content ensures excellent stress corrosion cracking resistance and oxidation resistance. Incoloy 825 also provides superior weldability, allowing for easy fabrication and installation. With excellent mechanical properties, including high strength and durability, these fittings are perfect for use in industries such as chemical processing, oil and gas, and power generation, ensuring long-lasting and reliable performance.

Incoloy 825 Buttweld Fittings Dimensions

Nominal PipeSize	Outside Diameter		90° Elbows		45° Elbows		180° Returns
*(inches)*	–		Long Radius	Short Radius	Long Radius		Long Radius
	*(mm)*	*(inches)*	Center to Face (inches)	Center to Face (inches)	Center to Face (inches)	Radius (inches)	Center to Center (inches)	Back to face (inches)
1/2	21.3	0.840	1 1/2	–	5/8		2	1 7/8
3/4	26.7	1.050	1 1/8		7/16		2 1/4	1 11/16
1	33.4	1.315	1 1/2	1	7/8		3	2 3/16
1 1/4	42.2	1.660	1 7/8	1 1/4	1		3 3/4	2 3/4
1 1/2	48.3	1.900	2 1/4	1 1/2	1 1/8	3	4 1/2	3 1/4
2	60.3	2.375	3	2	1 3/8	4	6	4 3/16
2 1/2	73.0	2.875	3 3/4	2 1/2	1 3/4	5	7 1/2	5 3/16
3	88.9	3.500	4 1/2	3	2	6	9	6 1/4
3 1/2	101.6	4.000	5 1/4	3 1/2	2 1/4	7	10 1/2	7 1/4
4	114.3	4.500	6	4	2 1/2	8	12	8 1/4
5	141.3	5.563	7 1/2	5	3 1/8	10	15	10 5/16
6	168.3	6.625	9	6	3 3/4	12	18	12 5/16
8	219.1	8.625	12	8	5	12	24	16 5/16
10	273.1	10.750	15	10	6 1/4	15	30	20 3/8
12	323.9	12.750	18	12	7 1/2	18	36	24 3/8

Types of Incoloy 825 Buttweld Fittings

Are Custom Sizes Available for Incoloy 825 Buttweld Fittings?

Yes, custom sizes for Incoloy 825 Buttweld Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.

825 Incoloy Alloy End Cap UAE, Incoloy® Alloy 825 180 Deg bend Sharjah, Incoloy Alloy 825 Pipe Bend Dubai, Jis Ncf 825 Pipe Fittings Abu Dhabi, Incoloy Alloy 825 Stub Ends Jebel Ali, Incoloy 825 Pipe End Cap Al Ain, 825 Incoloy Alloy End Cap Ajman, Incoloy® Alloy 825 Equal Tee Dubai, Ansi B16.9 800h Incoloy 45 / 90 / 180 Deg. Reducing Elbow UAE, Incoloy 825 Pipe Elbow Dubai, Supplier of Incoloy 825 45 degree Elbow UAE, Incoloy 10d Pipe Bend Abu Dhabi, 825 Incoloy Reducer, Incoloy® Alloy 825 Pipe bend Supplier in UAE.

Application Industry of Incoloy 825 Buttweld Fittings

Incoloy 825 Buttweld Fittings are extensively utilized in corrosive service conditions across several critical industries. They are perfect for piping systems in acid production plants, chemical processing units, offshore oil and gas platforms, pollution control equipment, and nuclear fuel reprocessing. These fittings excel in handling sulfuric, phosphoric, and nitric acids, along with seawater and other chloride-rich environments. Incoloy 825 combines strength, corrosion resistance, and durability, making it the go-to material for long-lasting performance in harsh industrial settings that involve high pressure and corrosive conditions.
