Kanak Fittings has established itself as a top player in the manufacturing and supply of high-quality pipe fittings in Dubai, UAE. With a specialization in Stainless Steel 17-4 PH Pipe Fittings, the company is dedicated to delivering products that meet the highest international standards. These fittings are designed for strength, precision, and durability, making them perfect for a wide range of industrial applications. Kanak Fittings prides itself on innovation and quality, striving to offer efficient and cost-effective solutions. Trusted by industries such as aerospace, marine, and petrochemicals, they ensure customer satisfaction through reliable products and outstanding service.
| Specification | ASTM A403 / ASME SA403 |
| Standard | EN, ISO, DIN, JIS, NPT |
| Dimension Standard | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Size | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Type | Seamless / Welded / Fabricated |
| Pressure-Temperature Class | 150LB, 300LB, 600LB, 1500LB, 2500LB. |
| Schedule | Schedule 5 TO Schedule XXS. |
| Type Of Dimension | BS1640, EN 10253 – 4, DIN 2605, JIS B2312, ANSI B16.9, MSS SP-75, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2313 |
17-4 PH Pipe Fittings, these fittings are made from a martensitic stainless steel alloy that includes chromium (15-17%), nickel (3-5%), copper (3-5%), along with small amounts of carbon, manganese, and silicon. The alloy’s unique precipitation-hardening characteristics boost its strength, corrosion resistance, and toughness. These fittings boast impressive tensile strength (up to 1,100 MPa) and maintain excellent mechanical stability, even in extreme temperatures and pressures. With remarkable fatigue and stress resistance, they comply with standards like ASTM A564, making them perfect for demanding environments where reliability is key.
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 17-4 PH | 0.07 max | 0.15-0.45 | 15.00-17.50 | 3.00-5.00 | Bal | 1.0 max | 3.0-5.0 | 0.40 max | 0.03 max | 1.0 max |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 17-4 PH | 170000 psi | 140000 psi | 6% | 38 |
Kanak Fittings one of the largest suppliers of Stainless Steel 17-4 PH Pipe Fittings in Dubai, UAE. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Stainless Steel 17-4 PH is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Stainless Steel 17-4 PH Pipe Fittings in the UAE.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 17-4 PH Pipe Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Stainless Steel 17-4 PH Pipe Fittings offer numerous advantages, including excellent corrosion resistance, even in harsh environments such as marine and chemical industries. Their high strength-to-weight ratio and superior mechanical properties ensure durability and reliability under high-pressure and high-temperature conditions. These fittings are easy to machine and weld, providing versatility in various applications. The alloy’s precipitation-hardening capability allows for adjustable strength levels through heat treatment, enhancing its adaptability. Additionally, they exhibit minimal distortion during heat processing, making them an ideal choice for precision-demanding applications like aerospace and petrochemical industries.
Yes, custom sizes are available for Stainless Steel 17-4 PH Pipe Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@kanakfittings.ae.
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-4 PH | 1.4542 | S17400 |
As for the Uses and Applications of Stainless Steel 17-4 PH Pipe Fittings, they are commonly found in industries that demand high strength and corrosion resistance, such as aerospace, chemical processing, marine, and oil and gas. These fittings excel in high-pressure and high-temperature settings, including hydraulic systems, fuel lines, and exhaust systems. Their outstanding resistance to stress-corrosion cracking makes them a go-to choice for tough operating conditions. Additionally, they are utilized in structural components, machinery, and equipment, ensuring long-lasting performance and lower maintenance costs.
