Kanak Fittings is a well-respected manufacturer and supplier of Stainless Steel 202 Pipe Fittings, proudly based in Dubai, UAE. They specialize in providing cost-effective and dependable piping solutions for a variety of industries. With a strong focus on quality, durability, and precision, Kanak offers a comprehensive range of SS 202 pipe fittings, including elbows, tees, reducers, and caps, all crafted to meet international standards. These fittings are celebrated for their impressive strength, decent corrosion resistance in mild environments, and affordability, making them perfect for general-purpose applications. Clients in construction, fabrication, and industrial sectors trust Kanak Fittings for their reliable performance and timely delivery.
| Specifications | : | ASTM A403 / ASME SA403 |
| Dimensions | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Size | : | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Thickness | : | SCH 5S, SCH 10S, SCH 20S, SCH 40S, SCH 80S, SCH 120S, SCH 1605, SCH XXS |
| Type | : | Seamless / Welded / Fabricated |
Stainless Steel 202 Pipe Fittings are crafted from an austenitic blend of chromium, nickel, and manganese, typically featuring around 17–19% chromium, 4–6% nickel, along with significant amounts of manganese and nitrogen. This unique composition results in a tensile strength of about 515 MPa and a yield strength of roughly 275 MPa. SS 202 is known for its good toughness, hardness, and resistance to mild corrosion and oxidation. While it may not be as corrosion-resistant as SS 304 or 316, it holds up well in less aggressive environments. Additionally, it is non-magnetic when annealed and offers excellent machinability, formability, and weldability, making it suitable for structural and moderate industrial applications.
| Grade 202 | C | Mn | Si | P | S | Cr | Ni | N |
| max. | 0.15 | 7.50-10 | 1 | 0.060 | 0.030 | 17- 19 | 4-6 | 0.25 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min |
| 202 | 515 | 275 | 40 |
Kanak Fittings one of the largest suppliers of Stainless Steel 202 Pipe Fittings in Dubai, UAE. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Stainless Steel 202 is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Stainless Steel 202 Pipe Fittings in the UAE.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 202 Pipe Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| STANDARD | UNS | WERKSTOFF NR. |
| SS 202 | S20200 | 1.4373 |
Stainless steel 202 pipe fittings enhance corrosion resistance, making it suitable for slightly corroded environments. They provide high strength and durability, providing long life even under high stress and temperature conditions. Their lightweight nature makes them easier to handle and install compared to other stainless steel products. The SS 202 fittings are cost-effective, providing performance at an affordable price. They also exhibit excellent weldability and machinability, facilitating fabrication. With their sleek finish, these inserts are ideal for decor and retain their shine over time, requiring minimal maintenance.
| Element | Density, lb/in3 | Modulus of Elasticity, psi | Linear Expansion, 68-212°F, /°F | Thermal Conductivity, Btu/ft hr°F | Heat Capacity, Btu/lb°F | Electrical Resistivity, Ω-inch |
| SS 202 | 0.285 | 29 x 106 | 9.4 x 10-6 | 8.7 | 0.12 | 27.6 x 10-6 |
| Nominal Pipe Size | Outside Diameter | 90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
|
(inches) |
Long Radius |
Short Radius |
Long Radius |
Long Radius |
||||
|
(mm) |
(inches) |
Center to Face
(inches) |
Center to Face
(inches) |
Center to Face
(inches) |
Radius
(inches) |
Center to Center
(inches) |
Back to face
(inches) |
|
|
1/2 |
21.3 |
0.840 |
1 1/2 |
– |
5/8 |
2 |
1 7/8 |
|
|
3/4 |
26.7 |
1.050 |
1 1/8 |
– |
7/16 |
2 1/4 |
1 11/16 |
|
|
1 |
33.4 |
1.315 |
1 1/2 |
1 |
7/8 |
3 |
2 3/16 |
|
|
1 1/4 |
42.2 |
1.660 |
1 7/8 |
1 1/4 |
1 |
3 3/4 |
2 3/4 |
|
|
1 1/2 |
48.3 |
1.900 |
2 1/4 |
1 1/2 |
1 1/8 |
3 |
4 1/2 |
3 1/4 |
|
2 |
60.3 |
2.375 |
3 |
2 |
1 3/8 |
4 |
6 |
4 3/16 |
|
2 1/2 |
73.0 |
2.875 |
3 3/4 |
2 1/2 |
1 3/4 |
5 |
7 1/2 |
5 3/16 |
|
3 |
88.9 |
3.500 |
4 1/2 |
3 |
2 |
6 |
9 |
6 1/4 |
|
3 1/2 |
101.6 |
4.000 |
5 1/4 |
3 1/2 |
2 1/4 |
7 |
10 1/2 |
7 1/4 |
|
4 |
114.3 |
4.500 |
6 |
4 |
2 1/2 |
8 |
12 |
8 1/4 |
|
5 |
141.3 |
5.563 |
7 1/2 |
5 |
3 1/8 |
10 |
15 |
10 5/16 |
|
6 |
168.3 |
6.625 |
9 |
6 |
3 3/4 |
12 |
18 |
12 5/16 |
|
8 |
219.1 |
8.625 |
12 |
8 |
5 |
12 |
24 |
16 5/16 |
|
10 |
273.1 |
10.750 |
15 |
10 |
6 1/4 |
15 |
30 |
20 3/8 |
|
12 |
323.9 |
12.750 |
18 |
12 |
7 1/2 |
18 |
36 |
24 3/8 |
Yes, custom sizes are available for Stainless Steel 202 Pipe Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@kanakfittings.ae.
Stainless Steel 202 Pipe Fittings find their place in general fabrication, architectural structures, and light-duty industrial piping systems. In construction, they are commonly used for railings, gates, and support frameworks, thanks to their strength and aesthetic appeal. Industries like food processing, automotive, and furniture manufacturing appreciate them as a budget-friendly alternative to more corrosion-resistant grades. These fittings are also utilized in water supply systems, storage tanks, and non-critical process lines. SS 202 pipe fittings are perfect for situations where high strength and moderate corrosion resistance are essential, all without the hefty price tag of premium options.
