Kanak Fittings has built a solid reputation as a reliable manufacturer and supplier of top-notch Stainless Steel 304 Buttweld Fittings in Dubai, UAE. Known for their commitment to quality and durability, Kanak Fittings caters to a diverse array of industries, including oil and gas, petrochemical, construction, and water treatment. Their cutting-edge manufacturing techniques and strict adherence to international standards guarantee dependable and cost-effective solutions. With a strong focus on quality, innovation, and customer satisfaction, Kanak Fittings has established itself as a leading supplier of Stainless Steel 304 Buttweld Fittings in the region.
| Specifications | ASTM A403 / ASME SA403 |
|---|---|
| Size | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | Seamless / Welded / Fabricated |
Stainless Steel 304 Buttweld Fittings are crafted from an austenitic stainless steel alloy that mainly consists of iron, chromium (18-20%), and nickel (8-10.5%), along with trace amounts of carbon, manganese, and silicon. These fittings are celebrated for their outstanding corrosion resistance, high ductility, and remarkable strength. They maintain their structural integrity even under high pressure and temperature, making them versatile for a variety of applications. Their tensile strength, yield strength, and elongation properties align with industry standards like ASTM A403, ensuring they are reliable and durable in challenging environments.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304 | min. | – | – | – | – | – | 18.0 | – | 8.0 | – |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | 0.10 | ||
| 304L | min. | – | – | – | – | – | 18.0 | – | 8.0 | – |
| max. | 0.030 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 12.0 | 0.10 | ||
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304 | 515 | 205 | 40 | 92 | 201 |
| 304L | 485 | 170 | 40 | 92 | 201 |
Kanak Fittings is a leading supplier of Stainless Steel 304 Buttweld Fittings in Dubai, UAE. We offer an extensive range of Stainless Steel 304 Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
|---|---|---|---|---|---|---|---|
| BS | En | No | Name | ||||
| 304 | S30400 | 304S31 | 58E | 1.4301 | X5CrNi18-10 | 2332 | SUS 304 |
| 304L | S30403 | 304S11 | 58E | 1.4306/1.4307 | X2CrNi18-9 / X2CrNi19-11 | 2332 | SUS 304L |
Stainless Steel 304 Buttweld Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Stainless steel 304 buttweld fittings provide excellent corrosion resistance, making them ideal for a variety of environments including marine and chemical applications Their long-lasting strength ensures long service life, and reduces replacement costs. These fittings have excellent weldability, providing easy and reliable installation. With great strength and strength, they withstand changes in pressure and temperature well. Their smooth interior reduces friction losses and increases flow efficiency in piping systems. Also, SS 304 is cost-effective compared to high-quality alloys while maintaining a luxurious appearance. These advantages make SS 304 buttweld fittings versatile for a variety of applications.
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
|---|---|---|---|---|---|---|---|---|
| (inches) | (mm) | (inches) | Length (inches) | Center to End (inches) | Center to End (inches) | Lap Diameter (inches) | Long Length (inches) | Short Length (inches) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
Yes, custom sizes for Stainless Steel 304 Buttweld Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.
Stainless Steel 304 Buttweld Fittings find extensive use in sectors such as oil and gas, food processing, chemical plants, and water treatment facilities. Their superior corrosion resistance makes them perfect for transporting liquids and gases in harsh environments. These fittings facilitate smooth directional changes, connections, and terminations in piping systems, promoting minimal turbulence and improved flow efficiency. Their versatility and compatibility with different piping configurations make them ideal for applications that demand hygienic and high-performance solutions, particularly in the pharmaceutical and beverage industries, where cleanliness and reliability are of utmost importance.
