Stainless Steel 347 / 347H Buttweld Fittings Manufacturer and Supplier in Dubai, UAE

Kanak Fittings stands out as a top-notch manufacturer and supplier of high-quality stainless steel pipe fittings in Dubai, UAE. With a focus on Stainless Steel 347 and 347H Buttweld Fittings, this company has built a reputation for providing strong and dependable solutions that cater to a wide range of industrial needs. Crafted with precision and in line with international standards, these fittings are perfect for various critical applications. Kanak Fittings’ dedication to quality, customer satisfaction, and prompt delivery has established it as a trusted name in the piping solutions industry, not just in the UAE but also beyond.

Stainless Steel 347 Pipe Elbow In UAE, Stainless Steel 347H Pipe Fittings Sharjah, SS 347 Buttweld Elbow Dubai, Stainless Steel S34700 Seamless Fittings Exporter Abu Dhabi, Stainless Steel 1.4550 Butt Weld Pipe Fittings in Jebel Ali, Stainless Steel 347H Two Joint Pipe Fittings Al Ain, 347 Stainless Steel Welded Fittings Manufacturers in Ajman, Stainless Steel 347H Buttweld Fittings In UAE, ASTM A403 WP3 347 Stainless Steel Buttweld Fittings Supplier in Dubai, UAE.

Stainless Steel 347 / 347H Buttweld Fittings Specification

Specifications	ASME SA403 / ASTM A403
Dimension Standard	ASME/ANSI B16.9, MSS-SP-43/SP-79, ASME B16.28, ASME B16.25, ASME B16.49
Standard Size Range	1/2” NB TO 48” NB. (Fabricated, Seamless and 100% X-Ray Welded)
Manufacturing Type	Fabricated / Seamless / Welded / ERW
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D, or Custom
Wall Thickness / Schedule	SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS / 3mm – 40mm
End Connection	Butt Weld
Melting Point	1400-1450°C for (WP317)
Outside Diameter (OD)	Seamless / Buttweld Fitting ( 1/2″～48″), ERW / Welded / Fabricated Buttweld Fitting (1/2″～48″)
Value Added Services	Hot Dipped Galvanizing, Electro Polish, Sand Blasting, Epoxy & FBE Coating, Threading, Soldering
Other Standards	MSS SP-75, ISO, SNSI, JIS, DIN, GB, DIN2617, JISB2311, JISB2312, JISB2313 / T12459GB / T13401, SH3408, SH3409HG / T21635HG / T21631SY / T05010
Material Test Certificates (MTC)	As per EN 10204 3.2 and EN 10204 3.1, Certifying NACE MR0175, NACE MR0103
Materials	AISI 317
Two Halve / Two Joint Buttweld Fittings Size	6″ to 48″
Manufacturing Specification	ASME: ANSI B16.9, ANSI B16.28, ASME B16.25, MSS-SP-43, DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011, EN: EN10253-1, EN10253-2
A403 SS Seamless Fittings	Size: 15 NB to 300 NB \| Sch.& Swg: Sch.5 to Sch.XXs
A403 SS Welded Fittings	Size: 15 NB to 600 NB \| Sch.& Swg: Sch.5 to Sch.80s

When it comes to the Composition and Mechanical Properties of Stainless Steel 347/347H Buttweld Fittings, these materials are austenitic stainless steels that are stabilized with niobium to avoid carbide precipitation during welding. Their makeup includes chromium (17-19%), nickel (9-13%), and small amounts of carbon and niobium. The 347H version has a higher carbon content, which boosts its strength at high temperatures. These fittings are known for their excellent resistance to intergranular corrosion and oxidation at elevated temperatures, along with impressive tensile and yield strength. Thanks to their outstanding mechanical properties and thermal stability, they are a reliable option for demanding applications.

Stainless Steel 347 / 347H Buttweld Fittings Chemical Composition

Element	C	Cr	Mn	Ni	P	S	Si	Cb/Ta
SS 347	0.08 max	min: 17.0 max: 20.0	2.0 max	min: 9.0 max: 13.0	0.04 max	0.30 max	0.75 max	min:10x C max: 1.0
SS 347H	min: 0.04 max: 0.10	min: 17.0 max: 20.0	2.0 max	min: 9.0 max: 13.0	0.03 max	0.30 max	0.75 max	min:10x C max: 1.0

Stainless Steel 347 / 347H Buttweld Fittings Mechanical Properties

Grade	Tensile Strength ksi (MPa) min	Yield Strength 0.2% ksi offset ksi (MPa) min	Elongation (% in 50mm) min	Hardness (Brinell) MAX	Hardness (Rockwell B) MAX
347/347H	75 (515)	30 (205)	40	201	95

ASTM A403 Stainless Steel 347 Buttweld Fittings Cross in UAE, Stainless Steel 1.4550 Buttweld Pipe Fittings Sharjah, SS 347H Butt Weld Pipe Cap Dubai, Stainless Steel 347 Eccentric Reducer Abu Dhabi, Stainless Steel 347 Equal Tee Jebel Ali, 347H Stainless Steel Reducer in Al Ain, Stainless Steel 347 SR Elbow Exporter in Ajman,

Largest Stainless Steel 347 / 347H Buttweld Fittings Supplier in Dubai, UAE

Kanak Fittings is a leading supplier of Stainless Steel 347 Buttweld Fittings in Dubai, UAE. We offer an extensive range of Stainless Steel 347H Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Stainless Steel 347 / 347H Buttweld Fittings Equivalent Grade

STANDARD	UNS	WNR.	EN	JIS	GOST
SS 347	S34700	1.4550	X6CrNiNb18-10	SUS 347	08Ch18N12B
SS 347H	S34709	1.4961	X6CrNiNb18-12	SUS 347H	–

Why Choose Stainless Steel 347 / 347H Buttweld Fittings from Kanak Fittings?

Stainless Steel 347 Buttweld Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

UNS S34709 Stub End Uk, ANSI B16.9 Stainless Steel 347 Pipe Fittings Sharjah, Stainless Steel 347H Pipe Bend Stockist in Dubai, Stainless Steel 347 Pipe Nipple Manufacturer & Exporter in Abu Dhabi, Stainless Steel 1.4961 Butt Weld Pipe Fittings in Jebel Ali, Stainless Steel 347 Pipe Two Joint Pipe Fittings Al Ain, 347H Stainless Steel Pipe Welded Fittings Manufacturers in Ajman, Stainless Steel 347 Pipe Butt weld Fittings In UAE, ASTM A403 Stainless Steel 347H Pipe Butt Weld Fittings Supplier in Dubai, UAE.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Stainless steel 347 and 347H Buttweld Fittings provide excellent resistance to intergranular corrosion, making them ideal for high temperature applications These alloys contain columbium and tantalum to stabilize the material and prevent carbide precipitation during welding. They are highly resistant to oxidation, providing long-term durability under extreme conditions. Stainless steel 347 provides excellent woldability and is suitable for applications in industries such as aerospace, chemical processing, and electrical equipment. The high-carbon 347H variant provides good strength at high temperatures, making it ideal for high-pressure environments.

Types of Stainless Steel 347 / 347H Buttweld Fittings

Stainless Steel 347 / 347H Buttweld Fittings Dimensions Chart

Nominal Pipe Size (inches)	Outside Diameter		45°Elbows		90° Elbows		180° Returns
	Outside Diameter		Long Radius		Long Radius	Short Radius	Long Radius
	(mm)	(inches)	Center to Face (inches)	Radius (inches)	Center to Face (inches)	Center to Face (inches)	Center to Center (inches)	Back to face (inches)
1	33.4	1.315	7/8		1 1/2	1	3	2 3/16
1/2	21.3	0.840	5/8		1 1/2	–	2	1 7/8
3/4	26.7	1.050	7/16		1 1/8	–	2 1/4	1 11/16
1 1/4	42.2	1.660	1		1 7/8	1 1/4	3 3/4	2 3/4
1 1/2	48.3	1.900	1 1/8	3	2 1/4	1 1/2	4 1/2	3 1/4
2	60.3	2.375	1 3/8	4	3	2	6	4 3/16
2 1/2	73.0	2.875	1 3/4	5	3 3/4	2 1/2	7 1/2	5 3/16
3	88.9	3.500	2	6	4 1/2	3	9	6 1/4
3 1/2	101.6	4.000	2 1/4	7	5 1/4	3 1/2	10 1/2	7 1/4
4	114.3	4.500	2 1/2	8	6	4	12	8 1/4
5	141.3	5.563	3 1/8	10	7 1/2	5	15	10 5/16
6	168.3	6.625	3 3/4	12	9	6	18	12 5/16
8	219.1	8.625	5	12	12	8	24	16 5/16
10	273.1	10.750	6 1/4	15	15	10	30	20 3/8
12	323.9	12.750	7 1/2	18	18	12	36	24 3/8

Are Custom Sizes Available for Stainless Steel 347 / 347H Buttweld Fittings?

Yes, custom sizes for Stainless Steel 347 / 347H Buttweld Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.

ASTM A403 Stainless Steel 347 Butt Weld Cross in UAE, Stainless Steel 1.4449 Buttweld Pipe Fittings Sharjah, SS 347H Butt Weld Pipe Cap Dubai, Stainless Steel 347 Eccentric Reducer Abu Dhabi, Stainless Steel 347H Equal Tee Jebel Ali, 347 Stainless Steel Reducer in Al Ain, SS 347H SR Elbow Exporter in Ajman,

Application Industry of Stainless Steel 347 / 347H Buttweld Fittings

As for the Uses and Applications of Stainless Steel 347/347H Buttweld Fittings, they find extensive use in sectors like oil and gas, power generation, chemical processing, and pharmaceuticals. They are particularly well-suited for high-temperature and corrosive environments, making them ideal for heat exchangers, boilers, and pressure vessels. Their resistance to intergranular corrosion allows for continuous operations in oxidizing conditions. Plus, these fittings guarantee secure and leak-proof connections in piping systems, ensuring long-term reliability when transporting steam, gases, and corrosive fluids across various industrial sectors.
