Kanak Fittings stands out as a reliable manufacturer and supplier of top-notch Stainless Steel 316H Buttweld Fittings in Dubai, UAE. Known for their precision and durability, these fittings are meticulously crafted to adhere to strict international standards. They’re specifically designed to handle high-temperature and pressure applications, serving a variety of industries including oil and gas, petrochemical, marine, and construction. By blending cutting-edge technology with rigorous quality control, Kanak Fittings ensures that their products are both dependable and efficient. Their dedication to excellence has made them a go-to choice for businesses looking for sustainable and cost-effective piping solutions in the region.
| Specifications | ASTM A403 / ASME SA403 |
| Size | Seamless Butt Weld Fittings: 1/2″ – 24″, Welded Butt Weld Fittings: 1/2″ – 48″ |
| Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | Seamless / Welded / Fabricated |
Stainless Steel 316H Buttweld Fittings are made up of chromium (16-18%), nickel (10-14%), molybdenum (2-3%), and a higher carbon content compared to standard 316 grades. This unique composition grants them exceptional corrosion resistance, particularly against chlorides and acidic environments, along with impressive mechanical properties at elevated temperatures. With enhanced tensile and yield strength, these fittings are perfect for high-pressure systems. Their ability to resist scaling and creep ensures they perform reliably even in extreme conditions, meeting international standards like ASTM A403 and ASME SA403.
| Grade | 316/316H/316L | |
|---|---|---|
| min | max | |
| C | – | 0.035 |
| Mn | – | 2.0 |
| Si | – | 0.75 |
| P | – | 0.045 |
| S | – | 0.030 |
| Cr | 16.0 | 18.0 |
| Mo | 2.0 | 3.0 |
| Ni | 10.0 | 14.0 |
| N | – | – |
Kanak Fittings is a leading supplier of Stainless Steel 304L Buttweld Fittings in Dubai, UAE. We offer an extensive range of Stainless Steel 304L Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 304L Buttweld Fittings from Kanak Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Stainless steel 316H Buttweld Fittings provide exceptional corrosion resistance, especially in high-temperature environments, making them ideal for chemical, petrochemical, and marine applications With high strength and durability these fittings maintain structural integrity in high-pressure and high-pressure conditions. The advanced carbon content of the 316H grade increases its strength at elevated temperatures, making it suitable for heat exchanger and boiler systems. These materials also exhibit excellent weldability and resist pitting, crevice corrosion, and chloride stress corrosion, providing durability and reliable performance in harsh environments.
| Nominal Pipe Size (inches) | Outside Diameter | 45°Elbows | 90° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
| Long Radius | Long Radius | Short Radius | Long Radius | |||||
| (mm) | (inches) | Center to Face (inches) | Radius (inches) | Center to Face (inches) | Center to Face (inches) | Center to Center (inches) | Back to face (inches) | |
| 1 | 33.4 | 1.315 | 7/8 | 1 1/2 | 1 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 | 1 7/8 | 1 1/4 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 1 1/8 | 3 | 2 1/4 | 1 1/2 | 4 1/2 | 3 1/4 |
| 1/2 | 21.3 | 0.840 | 5/8 | 1 1/2 | – | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 7/16 | 1 1/8 | – | 2 1/4 | 1 11/16 | |
| 2 | 60.3 | 2.375 | 1 3/8 | 4 | 3 | 2 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 1 3/4 | 5 | 3 3/4 | 2 1/2 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 2 | 6 | 4 1/2 | 3 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 2 1/4 | 7 | 5 1/4 | 3 1/2 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 2 1/2 | 8 | 6 | 4 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 3 1/8 | 10 | 7 1/2 | 5 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 3 3/4 | 12 | 9 | 6 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 5 | 12 | 12 | 8 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 6 1/4 | 15 | 15 | 10 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 7 1/2 | 18 | 18 | 12 | 36 | 24 3/8 |
Yes, custom sizes for Stainless Steel 304L Buttweld Fittings are available at Kanak Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@kanakfittings.ae.
Stainless Steel 316H Buttweld Fittings find extensive use in high-temperature and high-pressure applications across various industries. They play a crucial role in piping systems for oil and gas, chemical processing, power generation, pharmaceuticals, and marine engineering. Renowned for their durability and resistance to oxidation, these fittings are well-suited for corrosive and saline environments. They enable seamless connections, directional changes, and size transitions in pipelines, ensuring smooth fluid and gas flow. Their strength and longevity make them the preferred choice for critical applications that demand structural integrity and operational reliability.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
